SHADE Elevator is one of the global leaders in the elevator and escalator industry.
| Type Model | Travelling height mm | Net Weight (two set)KN | Support (two set) | Motor power KW | Dimension | ||
| R1 KN | R2 KN | h | i | ||||
| Fm I-302(800) (4800 persons/h) Speed 0.5m/s | 3000 | 118 | 104 | 94 | 5.5 | 2080 | 10900 |
| 3500 | 126 | 112 | 100 | 2110 | 11890 | ||
| 4000 | 134 | 120 | 108 | 2140 | 12880 | ||
| 4500 | 142 | 128 | 114 | 8 | 2160 | 13870 | |
| 5000 | 148 | 136 | 120 | 2170 | 14860 | ||
| 5500 | 164 | 148 | 132 | 2190 | 15860 | ||
| 6000 | 172 | 156 | 138 | 11 | 2200 | 16850 | |
| Fm I-302(1000) (4800 persons/h) Speed 0.5m/s | 3000 | 126 | 118 | 106 | 5.5 | 2080 | 10900 |
| 3500 | 134 | 128 | 114 | 8 | 2110 | 11890 | |
| 4000 | 142 | 136 | 122 | 2140 | 12880 | ||
| 4500 | 150 | 146 | 130 | 2160 | 13870 | ||
| 5000 | 166 | 158 | 142 | 11 | 2170 | 14860 | |
| 5500 | 174 | 168 | 150 | 2190 | 15860 | ||
| 6000 | 184 | 176 | 158 | 2200 | 16850 | ||
| 1000 | 1000 | 1238 | 1660 | 3500 | |||
| 800 | 800 | 1038 | 1460 | 3100 | |||
| Step width mm | A | B | C | D | |||
| Center support H3(L/2-2600)*tg30°- （ 897/cos30°+300 ） |
